Kverneland 8452
Kompakt - let at vedligeholde
Kompakt vender med lav vedligeholdelse
Højdepunkter
CompactLine-gearkasse med lav vedligeholdelse Kompakt spreder - lav vægt og lavt effektbehov Rotorplade dimension på 500 mm Dobbelte lejer fra pinion til kronehjulBeskrivelse
Kverneland 8452, med en arbejdsbredde på 5,2 m, har lave vedligeholdelseskrav og indeholder vedligeholdelsesvenlige funktioner som 500 mm rotorplader og en vedligeholdelsesvenlig gearkasse med kun én smørenippel. Kverneland 8452 kan justeres centralt for at flytte venderen til den ønskede position for kantvending. Hydraulisk drift og reduktionsgearkasse til natskår kan fås som ekstraudstyr.
Højdepunkter
- Lav vedligeholdelse af CompactLine-gearkassen med kun én smørenippel.
- Kompakt vender med lav vægt og lavt effektbehov.
- Rotorpladedimension på 500 mm.
- Dobbelte lejer fra tandhjul til kronhjul garanterer maksimal levetid for drivlinjen.
- Nem indstilling af spredevinklen gennem enkel trevejsjustering af hjulhøjden.
Funktioner
- The box type frame of the Kverneland 8000 series is an extremely solid construction. It is composed of two U-sections fitted into each other and securely welded together. The frame is totally enclosed at the top for maximum strength.
- All tedders have greasable pivoting points with an extra large diameter, making it a very strong and reliable construction.
- Made from flat steel, the tine arms form a very compact unit with the rotor plate. This makes the tedders by far more resistant to any type of load.
- High-quality forage allows the optimum spreading angle to be achieved according to crop conditions, helping you to produce high quality forage.
- Setting the rotors to the right spreading angle will considerably improve the spreading action, and speed up the drying process.
- The mower swaths are neatly lifted by the tines and evenly spread over the full width.
- Tines glide in a more uniform frequency over the stubble, so the risk of dirt being lifted by the tines is minimized.
Teknisk specifikation
Teknisk specifikation
Download brochure
You can select up to 5 models. Additional models are disabled. Please adjust your selection if you'd like to choose different models."
You can select up to 2 models. Additional models are disabled. Please adjust your selection if you'd like to choose different models.
At least 1 model must be selected. Please adjust your selection if you'd like to choose different models.
| Model CompactLine | 8452 | |
|---|---|---|
| Working width (m/ft) | 5.20 / (17’1”) | |
| Number of rotors | 4 | |
| Number of tines/rotor | 6 | |
| Transport width (m/ft) | 2.90 / (9’6”) | |
| Transport length (m/ft) | 2.10 / (6’11”) | |
| Storage height (m/ft) | 2.65 / (8’8”) | |
| Capacity theor. (ha/h) | 4.2 |
Unable to load the table
Teknisk specifikation
Teknisk specifikation
Download brochureModels |
Working Width |
Rotors/Tines |
Weight |
8446 |
4.60m |
4/5 |
495kg |
8452 |
5.20m |
4/6 |
520kg |
