*Based on average test conditions. Depending on soil type, moisture content, machine type, working speed, working depth, machine width and mounting position
Føler du dig ikke klar til den kommende sæson? Oplev XHD Hardface og XHD Carbide Reinforced dele, der giver din Kverneland rotorharve en enestående holdbarhed.
HØJDEPUNKTER
FORLÆNGET LEVETID TIL 10 GANGE*LÆNGERE.
ET OMKOSTNINGSEFFEKTIVT ALTERNATIV
MAKSIMAL VÆRDI FOR PENGENE
Fleksibel karbid belægning
Kverneland XHD Hardface-dele bruger en karbidbelægning til områder med moderat slid, hvilket forbedrer holdbarheden og fleksibiliteten på en omkostningseffektiv måde. Påført i lag skaber små plader af varmebehandlet karbid en elastisk overflade, der forhindrer brud og forlænger delens levetid.
Karbid dele
Wolframkarbid, der er fremstillet af wolframpulver og kobolt, er et af de hårdeste materialer. Kverneland XHD-dele bruger førsteklasses belægninger og svejsninger for at opnå overlegen holdbarhed og slagfasthed, hvilket sikrer lang levetid og omkostningseffektivitet.
Varmebehandlet stål
I modsætning til mange uoriginale dele er Kverneland XHD-dele varmebehandlet for at opnå optimal hårdhed og glathed. Dette sikrer en holdbar, friktionsfri overflade, der er ideel til hårde forhold. Kombineret med Hardface-forstærkning giver de uovertruffen holdbarhed.
Tougher hardfacing
Kverneland XHD Hardface dele anvender forskellige forstærkningsmetoder, hvor karbid-svejsning er den mest robuste. Denne teknik anvendes på dele, der udsættes for kraftigt slid, og forlænger delens levetid gennem en svejset belægning med en holdbar svejsetråd med karbidkerne.
AFRUNDEDE FLISER GØR EN FORSKEL
Oplev den exceptionelle holdbarhed af vores XHD karbid sliddele til Kverneland rotorharver. Med avanceret varmebehandling og svejseforstærkning i hårdmetal giver Kverneland XHD Hardface-tanden et overlegen greb, optimal indtrængning og minimal slitage, hvilket sikrer maksimal ydeevne og forlænget levetid.
- Afrundet kant for at udjævne presset.
- Sænket ned i tanden for ekstra holdbarhed.
Få sundere og stærkere jord med XHD carbide og XHD Hardface reservedele. Alt hvad du vil have til din Kverneland rotorharve!
XHD KARBID- OG HARDFACE-TÆNDER
Explore Kverneland's advanced XHD solutions designed for optimal field performance.
XHD Carbide Tine: The Next Level of Strength
Reinforced with Tungsten Carbide tiles, these tines ensure minimal wear and a uniform seedbed, available in 15mm (H Series) and 18mm (S Series).
XHD Hardface Tine: The Balance Between Strength and Cost
These tines are designed for abrasive soils and feature Carbide welding for extended lifespan and cost-effectiveness. Available in 15mm (H Series), 18mm (S Series), and 12mm (M Series).
The Kverneland XHD tine is reinforced with four premium grade Tungsten Carbide rounded tiles. The specially designed tiles even out the pressure on the cutting edge of the tine to allow optimum penetration and minimal length wear, ensuring a consistent depth and a homogeneous seedbed structure. The XHD tine is available in two versions; 15mm (H Series) and 18mm (S Series).
XHD CARBIDE POINT 15MM (H Series)
A156183986 - Left
A156184086 - Right
XHD CARBIDE POINT 18MM (S Series)
A156184186 - Left
A156184286 - Right
The Kverneland XHD Hardface tine is reinforced with Carbide welding. The tine is specially designed for the added Carbide welding to bond properly to the part and generate added strength to the cutting edge of the tine. This will allow optimum penetration and minimal length wear throughout the lifetime of the part. The XHD tine is available in three versions; 15mm (H Series); 18mm (S Series) and 12mm (M Series).
XHD HARDFACE TINE 15MM (H Series)
MA46010151S - Left
MA46010150S - Right
XHD HARDFACE TINE 18MM (S Series)
MA44010151S - Left
MA44010150S - Right
XHD HARDFACE TINE 12MM (M Series)
MAE020146S - Left
MAE010146S - Right
XHD ROLLERS PARTS
Find out more about Kverneland's XHD Hardface roller range, with carbide-coated parts that last 4 to 5 times longer. This process reinforces high-wear areas, reducing breakage and minimizing adjustment for consistent performance in all soil conditions.
Rollers XHD Parts include:
ActiLine roller:
XHD Scraper (before 2022) : A156174594
XHD Scraper (from 2022) : A156311794
FlexLine roller:
XHD Scraper FlexLine: A137097894
Packer roller :
XHD Scraper Ø500-575 (before 2022): RF23749
XHD Scraper 90mm (from 2022) : A156311094
The Kverneland XHD Hardface adjustable and reversible Scraper is reinforced with several layers of Carbide coating on both cutting edges. The coating thoughtfully placed with different thicknesses, based on how we know the scraper is wearing down over time. Carbide coating will extend the lifetime of the scraper and ensure to keep the machine blockage free during operation.
XHD HARDAFACE SCRAPER - 65MM
A156311794
The Kverneland XHD Hardface adjustable and reversible Scraper is reinforced with several layers of Carbide coating on both cutting edges. The coating thoughtfully placed with different thicknesses, based on how we know the scraper is wearing down over time. Carbide coating will extend the lifetime of the scraper and ensure to keep the machine blockage free during operation.
XHD HARDFACE RING ROLLER SCRAPER
A156174594
The Kverneland XHD Hardface adjustable Scraper is reinforced on the cutting edge with several layers of Carbide coating. This coating will extend the lifetime of the scraper and ensure to keep the machine blockage free during operation.
XHD HARDFACE SCRAPER
A137097894
The Kverneland XHD Hardface adjustable and reversible Scraper is reinforced with several layers of Carbide coating on both cutting edges. The coating thoughtfully placed with different thicknesses, based on how we know the scraper is wearing down over time. Carbide coating will extend the lifetime of the scraper and ensure to keep the machine blockage free during operation.
XHD HARDFACE SCRAPER - Ø500, 575
RF23749
The Kverneland XHD Hardface adjustable and reversible Scraper is reinforced with several layers of Carbide coating on both cutting edges. The coating thoughtfully placed with different thicknesses, based on how we know the scraper is wearing down over time. Carbide coating will extend the lifetime of the scraper and ensure to keep the machine blockage free during operation.
XHD HARDFACE SCRAPER - 90MM
A156311094
DELE TIL ROTORHARVE: BALANCEN MELLEM STYRKE OG OMKOSTNINGER
Ved at kombinere ekspertise fra varmebehandling med forstærkning fra karbid-svejsning giver vores XHD karbid-sliddele til Kverneland rotorharver en enestående holdbarhed. Kverneland XHD Hardface-tanden sikrer et stærkt greb, optimal indtrængning og minimal slitage i hele dens levetid.
Hver komponent afspejler vores engagement i bæredygtigt landbrug.
❝ We used to be changing non-genuine tungsten points every 300 acres, but since we've swapped to Kverneland XHD points, we've increased point life by around six to one. ❞ Read more
Clive Tedbury
From Sussex Agri Power - Kverneland UK.
DEN KOMPLETTE XHD-KARBID SERIE
Oplev XHD Karbid-serien - resultatet af ubarmhjertig innovation og grundige test i marken. Vores dele er konstrueret til at forbedre effektiviteten i dit landbrug. XHD Carbide har forstærkede dele, der giver uovertruffen holdbarhed og sikrer, at de kan modstå de hårdeste forhold.
Denne holdbarhed betyder øget effektivitet, betydelige tidsbesparelser og større rentabilitet for dit landbrug.
